T38-76mm Tungsten Carbide Threaded Button Bit with Ballistic and Spherical Buttons for Rock Drilling

Product Categories

KSQ Technologies (Beijing) Co. Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: T3876mm Tungsten Carbide Threaded Button Bit with Ballistic and Spherical Buttons for Rock Drilling
Brand: MIROC
Price: 1 USD

Brand Name : MIROC

Model Number : T38-76mm

Certification : ISO

Place of Origin : china

MOQ : 1

Supply Ability : 3000

Delivery Time : 20-30

Product : T38-76mm Button bit

Button Shape : Ballistic, Spherical, Composite buttons

Application : Bench drilling, underground production drilling, long hole drilling

Body : Retrac Skirt, Standard Skirt

Key Words : Rock Drilling Bit

Usage : Rock Drilling

Contact Now

T38-76mm Tungsten Carbide Threaded Button Bit

Product Description

Description: Threaded button bit

Raw material: Alloy steel and tungsten carbides

Thread: R25, R28, R32, R35, R38; T38, T45, T51, T60, ST58, ST68

Face: Flat front, drop center

Diameter: 35mm-127mm

Carbide: Ballistic, conical, spherical

Color: Customized

Application: Used to drill deep holes in underground mines, open pit mines, and tapholes

Customization: Thread, diameter, buttons number, button type, and flushing holes can be customized according to client's requirements and drawings

Key Features

Premium material with high-quality alloy steel and tungsten carbide from internationally renowned brands
Advanced heat treatment technology for high wear resistance
High toughness and wear resistance
Rich production experience and market feedback data from clients
Large capacity, stable quality, short lead time, competitive pricing

Specifications of Button Bits (T38)

Bit Dia. (mm)	Buttons and Size (mm)	Flushing Hole	Weight (kg)
64	310, 110 (Front) 6*11 (Gauge)	3 (Front)	1.7
70	310, 110 (Front) 6*12 (Gauge)	3 (Front)	1.8
76	311, 111 (Front) 6*12 (Gauge)	3 (Front) 1 (Side)	2.6
89	311, 211 (Front) 6*13 (Gauge)	3 (Front) 1 (Side)	3.3
